Description
LG Ceiling Concealed Duct Indoor Unit (36K class)
The LG ABNQ36GM2A2 is a ceiling concealed duct indoor unit in the 36K class, for cooling-only installations. It mounts above the ceiling and delivers conditioned air through ductwork, with adjustable external static pressure to suit different duct layouts. It pairs with the AUUQ36GH2 outdoor unit.
Key Features
- Cooling-only operation: built for cooling installations with no heating function.
- Concealed ceiling installation: mounts above the ceiling with air delivered through ductwork.
- Adjustable external static pressure: factory set at 10 mmAq, adjustable across a 4–10 mmAq range.
Technical Specifications
- Model code: ABNQ36GM2A2
- Type: Ceiling concealed duct indoor unit
- Operation: Cooling only
- Capacity class: 36K
- Paired outdoor unit: AUUQ36GH2 (also referenced as ABUQ36GM2A2)
- Power supply: 220 V~, 50/60 Hz
- Max current: 2.3 A
- External static pressure (factory setting): 10 mmAq (98 Pa)
- External static pressure (range): 4–10 mmAq (39–98 Pa)
- Max ESP setting value: 119
