LG Ceiling Concealed Duct Air Conditioner (48K class)
The LG ABUW48LM3S1 is an outdoor unit for a ceiling concealed duct air conditioning system in the 48K class. It works with a matched indoor unit to deliver conditioned air through ductwork, keeping the indoor equipment hidden above the ceiling.
Technical Specifications
- Model code: ABUW48LM3S1
- Type: Outdoor unit
- System type: Ceiling concealed duct
- Capacity class: 48K
- Refrigerant piping — gas: Ø19.05 mm (3/4 in)
- Refrigerant piping — liquid: Ø9.52 mm (3/8 in)
- Piping — maximum length: 50 m
- Piping — maximum elevation: 30 m
- Additional refrigerant charge: 40 g/m
- Piping — standard length: 7.5 m
- Piping — elevation (standard): 5 m
